Specifications |
Walls |
23/4"
thick concrete panels. Reinforced with 5.5mm steel rods, Multi spar
chipping finish |
|
Roof |
3"
profile fibre cement corrugated sheets |
Perlines |
2"
x 4" timber spaced at approx. 2'0" intervals |
Garage
Door |
Steel
Canopy up and over with 3 point locking as standard |
Back
Window |
3"
x 2" rebated framed window. Overall size 48" x 27" glazed,
puttied and latted |
Side
Window |
3"
x 2" rebated framed window. Overall size 48" x 35" slope
to 32 1/2" |
Personal
Door |
3"
x 2" door frame. Heavy duty matchboard batten door, nail / screw
fixing. Black japanned hook-bands. Dealock (key turn). Pull handle and
escutcheon (keyhole cover). |
Fascia |
Timber
made fascia using 4" x 2" frame, cladded with 1/2" weatherboard
and 6" x 1" p.s.e |
Bargeboards |
6"
x 1" p.s.e. full length of garage sides |
Fixings |
B.Z.P.
bolts etc. when possible. Galvanised nails. G.P. builder's mastics, foam
sealents. |
ALL
SIZES SHOWN ARE EXTERNAL DIMENSIONS
All
garages to include 2 up and over doors and
2 windows. All garages 18" wide and above
come complete with 2 x 8" wide up and
over garage doors |
|
